Peterbilt POD LED Headlights – Model 9600

Plug and Play Retrofit LED POD Style Headlights for Peterbilt 388/389, 567 & 589

Introducing the J.W. Speaker Model 9600 Peterbilt Headlights. For an exceptional punch of light down the road, giving ditch-to-ditch lighting coverage. This is a drop-in replacement for stock headlights for the Peterbilt 388/389, 567 & 589 trucks with Plug and Play functionality. The iconic POD light offers the unique “blade” design integrating turn signal performance with DRL and front position optics for a cutting-edge, eye-catching design — offering a signature, high-end look to complement the extensive lineup of Peterbilt trucks.

The Model 9600 LED headlight features: Smartheat® technology (optional) keeping the lens free of ice and snow, a built-in Bi-LED technology that switches between high and low beam, supports DRL, and built-in turn signal optics with a military-grade lens for anti-fog and UV protection.

Delivering superior visibility, durability, and longevity, the J.W. Speaker Model 9600 Headlight produces an exceptional punch of light down the road that gives ditch-to-ditch lighting coverage. Click here to see the headlight functions in action!

Smartheat® Technology:

SmartHeat® melts snow and ice off the lens to give Peterbilt drivers better visibility in cold, wintry weather to improve safety. When the low-temperature threshold is reached, the built-in intelligent grid system reacts in real-time, automatically heating the lens without driver intervention. Click here to learn more about Smartheat Technology.

Features and Benefits:

  • Front Position and Turn Signal Optics use a unique “blade” design
  • DOT compliant reflex optic and front side marker with feature lines
  • High and low beam delivers an exceptional punch and spread down the road
  • The Bi-LED module allows for digital switching for the high and low beam optic, removing failure point of mechanical system
  • Optional Smartheat® technology keeping the lens free of ice and snow
  • Plug-and-play functionality for Peterbilt heavy-duty truck models with select pod-style headlights
  • Chrome and Black Bezel options available with black polycarbonate housing
  • 12V Input Voltage
  • Wire Harnesses sold separately

Overview:

Upgrade your Peterbilt heavy-duty truck with top-of-the-line headlights from J.W. Speaker and enjoy excellent lighting performance. Delivering bright illumination, they effectively light the way during the night and enable safe driving while giving the truck a dream exterior, rediscovering its beauty in a new way.

*If your Peterbilt heavy-duty truck already supports DRL function, the model 9600 will support the function. If it doesn’t support DRL, the light will not add DRL to your vehicle.

Wire harnesses are now sold separately.
Start by picking your headlights, then choose which harness is best suited for your specific vehicle model and year.

Questions?

Click here to speak with one of our Lighting Experts.

Applications
  • Truck & Bus
This product meets one or more FMVSS 108 standards, including DOT and Transport Canada requirementsThis product is sealed to completely protect against the entry of dust and immersion in water up to a depth of 1 meter.This product meets one or more Society of Automotive Engineers regulatory standards.
Share this Product
Specifications Dealer Locator
Peterbilt 389/388 LED Headlight Replacement - Model 9600 Peterbilt 389 LED Headlight Model 9600 RH Chrome Front View Peterbilt 389 LED Headlight Model 9600 RH Chrome 34 View Peterbilt 389 LED Headlight Model 9600 RH Chrome Side View Peterbilt 389 LED Headlight Model 9600 RH Chrome Side View LED Model 9600 Heated Black Peterbilt POD LED Headlight on Blue Peterbilt LED Truck Headlights Models 8800 Evolution 2 and 9600 Chrome Peterbilt POD Light LED Model 9600 Chrome Peterbilt POD LED Headlight on Silver Semi LED Model 9600 Heated Black Peterbilt POD LED Headlight on Blue Peterbilt LED Model 9600 Chrome Peterbilt POD LED Headlight on Blue Semi LED Model 9600 Chrome Peterbilt POD LED Headlight on Blue Semi LED Truck SmartHeat Headlights Model 9600 Chrome Peterbilt POD Light
For California residents:
⚠️ WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov.
⚠️ AVERTISSEMENT: Cancer et effet nocif sur la reproduction - www.P65Warnings.ca.gov.

Part Numbers (Heated)

  Part NumberDescriptionPrice (U.S. only)Spec Sheet
0562511 Part 0562511 12V Peterbilt LED Heated Headlight, Left-hand, Chrome Bezel (Single Light, Harness Sold Separately)DownloadPDF
  Complies with: FMVSS 108 s10.1 (Table XIX), FMVSS 108 s10.1 (Table XVIII), FMVSS 108 s7.1 (Table VI), FMVSS 108 s7.4 (Table X), FMVSS 108 s8.1 (Table XVI), IEC IP67, SAE J588, SAE J592, SAE J594
0562521 Part 0562521 12V Peterbilt LED Heated Headlight, Right-hand, Chrome Bezel (Single Light, Harness Sold Separately)DownloadPDF
  Complies with: FMVSS 108 s10.1 (Table XIX), FMVSS 108 s10.1 (Table XVIII), FMVSS 108 s7.1 (Table VI), FMVSS 108 s7.4 (Table X), FMVSS 108 s8.1 (Table XVI), IEC IP67, SAE J588, SAE J592, SAE J594
0562551 Part 0562551 12V Peterbilt LED Heated Headlight, Left-hand, Black Bezel (Single Light, Harness Sold Separately)DownloadPDF
  Complies with: FMVSS 108 s10.1 (Table XIX), FMVSS 108 s10.1 (Table XVIII), FMVSS 108 s7.1 (Table VI), FMVSS 108 s7.4 (Table X), FMVSS 108 s8.1 (Table XVI), IEC IP67, SAE J588, SAE J592, SAE J594
0562561 Part 0562561 12V Peterbilt LED Heated Headlight, Right-hand, Black Bezel (Single Light, Harness Sold Separately)DownloadPDF
  Complies with: FMVSS 108 s10.1 (Table XIX), FMVSS 108 s10.1 (Table XVIII), FMVSS 108 s7.1 (Table VI), FMVSS 108 s7.4 (Table X), FMVSS 108 s8.1 (Table XVI), IEC IP67, SAE J588, SAE J592, SAE J594

Part Numbers (Non-Heated)

  Part NumberDescriptionPrice (U.S. only)Spec Sheet
0562531 Part 0562531 12V Peterbilt LED Headlight, Left-hand, Chrome Bezel (Single Light, Harness Sold Separately)DownloadPDF
  Complies with: FMVSS 108 s10.1 (Table XIX), FMVSS 108 s10.1 (Table XVIII), FMVSS 108 s7.1 (Table VI), FMVSS 108 s7.4 (Table X), FMVSS 108 s8.1 (Table XVI), IEC IP67, SAE J588, SAE J592, SAE J594
0562541 Part 0562541 12V Peterbilt LED Headlight, Right-hand, Chrome Bezel (Single Light, Harness Sold Separately)DownloadPDF
  Complies with: FMVSS 108 s10.1 (Table XIX), FMVSS 108 s10.1 (Table XVIII), FMVSS 108 s7.1 (Table VI), FMVSS 108 s7.4 (Table X), FMVSS 108 s8.1 (Table XVI), IEC IP67, SAE J588, SAE J592, SAE J594
0562571 Part 0562571 12V Peterbilt LED Headlight, Left-hand, Black Bezel (Single Light, Harness Sold Separately)DownloadPDF
  Complies with: FMVSS 108 s10.1 (Table XIX), FMVSS 108 s7.1 (Table VI), FMVSS 108 s7.4 (Table X), FMVSS 108 s8.1 (Table XVI), IEC IP67, SAE J588, SAE J592, SAE J594
0562581 Part 0562581 12V Peterbilt LED Headlight, Right-hand, Black Bezel (Single Light, Harness Sold Separately)DownloadPDF
  Complies with: FMVSS 108 s10.1 (Table XIX), FMVSS 108 s10.1 (Table XVIII), FMVSS 108 s7.1 (Table VI), FMVSS 108 s7.4 (Table X), FMVSS 108 s8.1 (Table XVI), IEC IP67, SAE J588, SAE J592, SAE J594

Dimensions

Part Accessories

Part NumberDescriptionPrice (U.S. only)Spec Sheet
3271081 Part 3271081 Wire Harness for Peterbilt Trucks 388, 389, & 567, Years 2023 and OlderDownloadPDF
3272531 Part 3272531 Wire Harness for Peterbilt Trucks 567 & 589, Years 2024 and NewerDownloadPDF
