LED Compact Work Light – Model 792

3" x 4" Work Light Buy Now

Operating equipment and machinery in dark environments require workers to rely on consistent and quality lighting to remain safe and productive while working. The operating conditions in agriculture, industrial, construction, and mining environments represent a unique set of challenges for workers, as changes in weather conditions and daily use are a daily occurrence. Click Here to Learn More About the Compact Work Light Series.

The J.W. Speaker Model 792 LED Compact Work Lights are engineered for the most demanding conditions. Manufactured to endure rigorous requirements for stability and resistance to the elements while also producing powerful flood/trap light patterns to illuminate the darkest worksites keeps production moving and workers safe.  This light is available in pedestal or panel mount options to fit a large variety of applications.

J.W. Speaker, known for manufacturing high-performance LED technology, developed these compact work lights to be used in the harshest working conditions with 2,000 effective lumens of powerful light output, providing crucial illumination for the safety, productivity, and comfort of workers. These low-profile LED work lights provide bright white light for agricultural, construction, and industrial applications that require reliable, high-quality LED lighting to withstand vibrations, impacts, and deliver consistent performance over time under harsh environments.

Features and Benefits:

  • Available in pedestal or panel mount options
  • Powerful 2,000 effective lumens of light output in a flood/trap pattern
  • Durable polycarbonate lens is impact resistant
  • Aluminum black housing is durable and corrosion-resistant
  • Low-profile Pedestal Dimensions: Height: 2.7in, Width: 4in, Depth: 1.7in
  • Low-profile Panel Dimensions: Height: 2in, Width: 4in, Depth: 1.7in
  • Input Voltage: 12/24V or 36/90V
  • Complies with ECE Reg. 10
  • Rated IP67 & IP69K

Overview:

Engineered with tight spaces in mind, the low-profile design of the Model 792 LED Compact Work Light provides a compact lighting option for agricultural, construction, and industrial vehicles. This durable light is available in both pedestal and panel mount options to fit a large variety of applications. Support accident prevention by replacing inferior halogen lights with the Model 792.

Applications
  • Agriculture
  • Construction
  • Industrial
  • Material Handling
  • Mining
  • Off-Road 4x4
  • Railroad
  • Specialty Vehicles
Made in USAThis product meets one or more European regulatory standards. Please see the specification sheet for more details.This product is sealed to completely protect against the entry of dust and immersion in water up to a depth of 1 meter.This product is sealed to completely protect against the entry of dust and high-pressure/high-temperature jets of water in any direction.
Share this Product
Specifications Dealer Locator
LED Work Light Model 792 with Pedestal Mount Black PCB Front View
LED Work Light Model 792 with Pedestal Mount Black PCB Front View LED Work Light Model 792 with Pedestal Mount Black PCB 34 View LED Work Light Model 792 with Pedestal Mount Side View LED Work Light Model 792 with Pedestal Mount Back View Model 792 Work Light Panel Mount Model 792 LED Compact Work Light Illuminating Trucks Model 792 LED Compact Work Light Illuminating Trucks Model 792 Construction Lifestyle Image LED Compact Work Light Model 792 and 893 on Tractor J.W. Speaker - Model 792 on Snow Dog Trail Groomer Model 260 ECE Clear Lens and Model 792 on Transport Vehicle
For California residents:
⚠️ WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov.
⚠️ AVERTISSEMENT: Cancer et effet nocif sur la reproduction - www.P65Warnings.ca.gov.

Part Numbers (Single)

The following lights are available as singles.

  Part NumberDescriptionPrice (U.S. only)Spec Sheet
1603921 Part 1603921 12-24V LED Compact Work Light with Pedestal Mount$79.98DownloadPDFBuyAdd to Cart
  Complies with: Buy America Standards, ECE Reg 10, IEC IP67, IEC IP69K, Tested to ECE Reg. 10 (Radiated Emissions only)
1603951 Part 1603951 12-24V LED Compact Work Light with Panel MountDownloadPDF
  Complies with: Buy America Standards, ECE Reg 10, IEC IP67, IEC IP69K, Tested to ECE Reg. 10 (Radiated Emissions only)
1603931 Part 1603931 36-80V LED Compact Work Light with Pedestal Mount$79.98DownloadPDFBuyAdd to Cart
  Complies with: Buy America Standards, ECE Reg 10, IEC IP67, IEC IP69K, Tested to ECE Reg. 10 (Radiated Emissions only)
1603971 Part 1603971 36-80V LED Compact Work Light with Panel MountDownloadPDF
  Complies with: Buy America Standards, ECE Reg 10, IEC IP67, IEC IP69K, Tested to ECE Reg. 10 (Radiated Emissions only)

Part Numbers (Bulk)

The following lights are available in bulk quantities.

  Part NumberDescriptionPrice (U.S. only)Spec Sheet
1603932 Part 1603932 36-90V LED Compact Work Light with Pedestal Mount (BULK with Harness)DownloadPDF
  Complies with: IEC IP67, IEC IP69K, Tested to ECE Reg. 10 (Radiated Emissions only)

Dimensions
